Technical dataAdditional data Rated input power* 1,500 W Impact energy* 12.5 J Impact rate at rated speed 1,380 – 2,760 bpm Rated speed 0 – 305 rpm Weight 8.9 kg Tool dimensions (width) 116 mm Tool dimensions (length) 540 mm Tool dimensions (height) 310 mm Tool holder SDS max
Drilling range Drilling dia. concrete, hammer drill bits* 12 – 45 mm Opt. appl. range concrete, hammer drill bits 20 – 40 mm Drilling dia. concrete, breakthrough drill bits 80 mm Drilling diameter in concrete with core cutters 125 mm
Total vibration values (Hammer drilling in concrete) Vibration emission value ah 8 m/s² Uncertainty K 1.5 m/s²
Total vibration values (Chiselling) Vibration emission value ah 7 m/s² Uncertainty K 1.5 m/s²
* Highlighted Data
The A-rated noise level of the power tool is typically as follows: Sound pressure level 96 dB(A); Sound power level 107 dB(A). Uncertainty K= 3 dB.
Technical data
| Additional data | |
|---|---|
| Rated input power* | 1,500 W |
| Impact energy* | 12.5 J |
| Impact rate at rated speed | 1,380 – 2,760 bpm |
| Rated speed | 0 – 305 rpm |
| Weight | 8.9 kg |
| Tool dimensions (width) | 116 mm |
| Tool dimensions (length) | 540 mm |
| Tool dimensions (height) | 310 mm |
| Tool holder | SDS max |
| Drilling range | |
|---|---|
| Drilling dia. concrete, hammer drill bits* | 12 – 45 mm |
| Opt. appl. range concrete, hammer drill bits | 20 – 40 mm |
| Drilling dia. concrete, breakthrough drill bits | 80 mm |
| Drilling diameter in concrete with core cutters | 125 mm |
| Total vibration values (Hammer drilling in concrete) | |
|---|---|
| Vibration emission value ah | 8 m/s² |
| Uncertainty K | 1.5 m/s² |
| Total vibration values (Chiselling) | |
|---|---|
| Vibration emission value ah | 7 m/s² |
| Uncertainty K | 1.5 m/s² |
* Highlighted Data
The A-rated noise level of the power tool is typically as follows: Sound pressure level 96 dB(A); Sound power level 107 dB(A). Uncertainty K= 3 dB.
