Technical data

Additional data
Rated input power*	1,350 W
Impact energy*	2 - 15 J
Impact rate at rated speed	1,375 – 2,800 bpm
Rated speed	145 – 280 rpm
Weight	8.2 kg
Tool dimensions (width)	288 mm
Tool dimensions (length)	545 mm
Tool dimensions (height)	105 mm
Tool holder	SDS max

Drilling range
Drilling dia. concrete, hammer drill bits*	12 – 45 mm
Opt. appl. range concrete, hammer drill bits	25 – 40 mm
Drilling dia. concrete, breakthrough drill bits	45 – 80 mm
Drilling diameter in concrete with core cutters	40 – 150 mm

Total vibration values (Hammer drilling in concrete)
Vibration emission value ah	21 m/s²
Uncertainty K	1.5 m/s²

Total vibration values (Chiselling)
Vibration emission value ah	15 m/s²
Uncertainty K	1.5 m/s²

* Highlighted Data

The A-rated noise level of the power tool is typically as follows: Sound pressure level 95 dB(A); Sound power level 106 dB(A). Uncertainty K= 3 dB.
