Technical data

Additional data
Rated input power*	800 W
Impact energy*	3.1 J
Tool dimensions (length)	326 mm
Impact rate at rated speed	0 – 4,000 bpm
Rated speed	0 – 900 rpm
Weight	3.6 kg
Tool dimensions (height)	233 mm
Tool holder	SDS plus

Drilling range
Drilling dia. concrete, hammer drill bits*	4 – 28 mm
Opt. appl. range concrete, hammer drill bits	12 – 18 mm
Drilling diameter in concrete with core cutters	68 mm
Max. drilling diameter masonry, core cutters	82 mm
Max. drilling diameter in metal	13 mm
Max. drilling diameter in wood	30 mm

Total vibration values (Hammer drilling in concrete)
Vibration emission value ah	14.5 m/s²
Uncertainty K	1.6 m/s²

Total vibration values (Chiselling)
Vibration emission value ah	10 m/s²
Uncertainty K	1.5 m/s²

* Highlighted Data

The A-rated noise level of the power tool is typically as follows: Sound pressure level 91 dB(A); Sound power level 102 dB(A). Uncertainty K= 3 dB.
